Hassle-Free ReturnsEmbracing Morel’s legendary craftsmanship, engineering, and innovation, the latest Hybrid systems define an ever-evolving concept of high-fidelity speaker design. Now in their fifth generation, the new Hybrid and Hybrid Integra systems give a further refined listening experience, captivating you with the raw emotions of listening to live music. Their subtle balance of resolution, power, and efficiency has been further optimized to exceed expectations regardless of what genre of music you enjoy. Now the Hybrid is available in 2-way and Integra point source (coaxial) solutions, as well as a new 3-way system to fit nearly any system requirement.
| MODEL | SIZE & CONFIGURATION | POWER HANDLING (RMS) / PEAK POWER (W) | SENSITIVITY (DB) | FREQUENCY RESPONSE (HZ) |
|---|---|---|---|---|
| HYBRID 42 | 4” 2-way | 100 / 300 | 89 | 50-25000 |
| HYBRID 52 | 5¼” 2-way | 120 / 500 | 90 | 45-25000 |
| HYBRID 62 | 6½" 2-way | 140 / 600 | 91 | 35-25000 |
| MODEL | HYBRID MW6 |
|---|---|
| Nominal Impendance (ohm) 4 | 4 |
| Power Handling Wrms | 140 |
| Max. Trans. Pwr Handling Wrms | 600 |
| Sensitivity (2.83 V/1M) dB | 91 |
| Frequency response Hz | 35 - 3000 |
| Resonant Freq. Fs Hz | 45 |
| Voice Coil Diameter mm (inch) | 54 (2.1) |
| Voice Coil Height mm (inch) | 11 (0.47) |
| Voice Coil Type/Former | Aluminium |
| Voice Coil Wire | Hexatech™ Aluminium |
| DC Resistance (ohm) | 3 |
| Voice Coil Induct. @1 kHz (mH) | 0.22 |
| Magnet System | Hybrid rear vented |
| HE-Magnetic Gap Height mm (inch) | 4 (0.16) |
| B-Flux Density (T) | 0.83 |
| BL Product/BXL | 4.2 |
| Max. Linear Ex./Xmax mm (inch) | 7 ± 3.5mm (0.28 ± 0.14) |
| Suspension Compliance CMS - mm/N | 1.1 |
| Electrical Q Factor QES | 0.56 |
| QTS | 0.44 |
| QMS | 2.08 |
| Mech. Resistance RMS- N . S / M | 1.5 |
| Moving Mass MMS - gr/ounce | 11 |
| Equiv. Can Air Load VAS - L (cu.ft3) | 21 (0.74) |
| Effective Piston Area SD sq.cm (sq.inch) | 119 (18.45) |
| Cone Type | One-piece formed |
| Cone Material | DPC |
| Unit Diameter mm(inch) | 165 (6.50) |
| Mounting Depth mm (inch) | 61 (2.40) |
| Mounting Cutout | 141 (5.55) |
| Net Wight Kg (lb) | 0.60 (1.32) |
| Speaker Size (in) | 6.5" |
|---|---|
| Style | Component |
| RMS Power (W) | 140 |
| Peak Power (W) | 600 |
| Sensitivity (dB @ 1W/1m) | 91 |
| Frequency Response (Hz) | 35-25k |
| Mounting Hole Diameter (cm) | 14.1 |
| Mounting Depth (cm) | 6.1 |
| Single Or Pair | Pair |
| Grills | Included |
| Brand | Morel |
| EAN | 14729010592216 |
| Box Quantity | No |
