AM/FM Flexible Roof Mount Antenna for Heavy Duty Machinery
The ANC7667010 antenna is the perfection combination of high quality AM/FM reception with a build that will survive the harshest of environments. The flexible whip is weather resistant and able to withstand high mechanical stress, making it suitable for heavy duty machinery such as agricultural or construction vehicles.
This is designed for installation on a vehicle roof. The ANC7677012 has a similar construction but is suitable for wing or pillar mounting.
Cable length: 2.5m
Whip length: 25cm
Inclination: 0° - 90°
Total length including base: 28cm
Purpose | AM/FM |
---|---|
Install Location | Roof |
Active | No |
Mast Angle | Adjustable 0-90 |
Mounting Hole Diameter (cm) | See Technical Tip tab |
Connection | DIN |
Cable Length (m) | 2.4 |
Cable Type | Coaxial |
Waterproof Rating | IP68 |
Width (cm) | 3.7 |
Depth (cm) | 4.2 |
Brand | Calearo |
EAN | 8010925650923 |
The ANC7667010 antenna requires 2 mounting holes. One for the mounting bolt and another, toward the rear of the vehicle, for a plastic locating pin. The front bolt hole (A) should be 8mm in diameter. The rear locating pin hole (B) should be 4.7mm in diameter. The 2 holes should be spaced 14mm apart, centre to centre.
To securely fasten to the coachwork the ANC7667010 must use an AM/FM cable with washer style connector, similar to the below. This antenna comes complete with a 2.4m cable with this connector.
